Fiber Laser Seed Fs/Ps

STLY Series Fiber Laser Seed

1. STLY Series 780nm Femtosecond Fiber Laser Seed

The 780nm femtosecond fiber seed source is a modular near-infrared femtosecond laser light source. It has an output wavelength of 780nm, a pulse width of less than 100fs, a spectral width of more than 9nm, and a repetition frequency of 80MHz. This 780nm femtosecond fiber laser is based on key technologies such as fully automatic mode-locked pulse generation, low-nonlinearity and low-noise fiber amplification, high-precision dispersion compensation, and high-efficiency frequency conversion. It has achieved a miniaturized and integrated design of the laser's optics, mechanics, and electronics, featuring extremely high reliability and stability. In addition, our same type of laser also supports the dual-wavelength synchronous output function of 780/1560nm, and the repetition frequency can be selected within the range of 10-100MHz, meeting the requirements of a variety of application scenarios.

Features

• Optoelectronic integrated design

• Ultrashort pulses ≤ 100 fs

• Spectral width > 9 nm

• High pulse contrast ratio

Applications:

• THz time-domain spectroscopy

• Laser ranging, micro-nano 3D printing

• Fiber/solid-state laser seed source

Specifications

2. STLY Series 1030/1053/1064 nm Picosecond Fiber Laser Seed

The picosecond fiber seed source is a picosecond seed source with a fixed repetition frequency in the near-infrared band. Its output wavelengths are 1030nm, 1053nm and 1064.3nm, the pulse width is 10ps, the spectral width is less than 0.5nm, and the repetition frequency is 20MHz. Based on key technologies such as high-isolation pump protection, fully automatic mode-locked pulse generation, low-nonlinearity and low-noise fiber amplification, this picosecond fiber seed source has achieved a compact and integrated design. It can be used right away after being plugged in and features extremely high reliability and stability. In addition, our lasers of the same type also provide optional parameter outputs within the range of a wavelength from 1030nm to 1080nm, a pulse width from 4ps to 120ps, and a repetition frequency from 10MHz to 80MHz, meeting the requirements of various industrial and scientific research application scenarios.

Specifications

Ordering Information / Product Code

1064 nm Ps Fiber Laser Seed Specifications

3. STLY Series 1030/1053/1064 nm Tunable Repetition Frequency Picosecond Fiber Laser Seed

The tunable repetition frequency picosecond fiber seed source has an output wavelength of 1030/1053/1064.3nm. The repetition frequency is adjustable within the range of 50kHz to 10MHz, and the pulse width can be customized within the range of 10ps to 120ps. The spectral width is less than 1nm, and it features a burst trigger mode. This 1064nm tunable repetition frequency picosecond fiber seed source is based on key technologies such as high-isolation pump protection, fully automatic mode-locked pulse generation, low-nonlinearity and low-noise fiber amplification, etc. It has achieved a compact and integrated design and possesses extremely high reliability and stability.

Specifications

4. STLY Series 1030 nm Femtosecond Fiber Laser Seed

The 1030nm femtosecond fiber seed source is a femtosecond seed source with a fixed repetition frequency. Its output wavelength is 1030nm, the repetition frequency is 25MHz, the spectral width is 10nm, and it has a linear chirp. The pulse width directly output by the laser is 2ps, and the pulse width after de-chirping is less than 300fs. This 1030nm femtosecond fiber seed source is based on key technologies such as high-isolation pump protection, fully automatic mode-locking pulse, low-nonlinearity, and low-noise fiber amplification. It achieves a compact and integrated design, has extremely high reliability and stability, and meets the requirements of a variety of industrial and scientific research application scenarios.

Specifications

5. STLY Series 1030 nm Tunable Repetition Rate Femtosecond Fiber Laser Seed

The 1030nm tunable repetition rate femtosecond fiber seed source is a femtosecond laser light source in the near-infrared band, and it is the best seed source for high-energy femtosecond lasers. The output wavelength is 1030nm, with a directly output pulse width of 4ps or it can be broadened to several hundred picoseconds through CFBG. After de-chirping, the pulse width is less than 300fs. The repetition rate can be adjusted within the range of 50kHz to 10MHz, and it has a burst trigger mode. This 1030nm tunable repetition rate femtosecond fiber seed source is based on key technologies such as high-isolation pump protection, fully automatic mode-locked pulse generation, low-nonlinearity and low-noise fiber amplification, etc. It realizes the output of highly stable and reliable seed pulses, and can meet the needs of various industrial and scientific research application scenarios.

Specifications

6. STLY Series 1560 nm Femtosecond Fiber Laser Seed

The 1560nm femtosecond fiber seed source is a femtosecond laser in the near - infrared band. It has an output wavelength of 1560nm, a pulse width of up to 50fs, and a repetition rate of 80MHz. This 1560nm femtosecond fiber laser integrates core technologies such as high - isolation pump protection, fully automatic mode-locked pulses, low-nonlinearity/low-noise fiber amplification, and high-precision dispersion compensation. It boasts extremely high reliability and stability.

Specifications

*STLY-1560-FS-D is a model with two output ports. The power ratio between the two ports can be preset by an inset fiber coupler, such as 40:60 or 50:50.
